Description
| Model | PLC-425M-AI-IR3/PR |
|---|---|
| Image Sensor | 1/2.8″ SONY Starvis Back-illuminated CMOS Sensor |
| Resolution | 5 MP |
| Effective Pixels | 2616 (H) x 1964 (V) |
| Compression | H.264/H.264+/H.265/H.265+/JPEG/AVI /MJPEG |
| TV System | PAL/NTSC |
| Electronic Shutter Time | Auto: PAL 1/25 s – 1/10000 s; NTSC 1/25 s – 1/10000 s |
| Minimum Illumination | 0.01 Lux |
| S/N Ratio | ≥52 dB |
| Scanning System | Progressive |
| Video Output | Network |
| Reset Button | Optional |
| Focal Length | 3.6 mm |
| Focus Control | Fixed |
| Lens Type | Fixed |
| Pixels | 5 MP |
| Infrared LED | 42µx2PCS |
| Infrared Distance | 30 m |
| IR Status | Auto-control |
| IR Power On | Auto-control |
| Ethernet | RJ-45 (10/100 Base – T) |
| Protocol | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, SMTP |
| ONVIF | Supports ONVIF 2.4 |
| P2P | Yes, Supports QR Code |
| PoE | Optional/Internal, Supports IEEE 802.3af |
| Video Delay | 0.3 s (Within the Lan) |
| Main Stream 1 | 2592 * 1944 @ 20 fps – 2560 * 1920 @ 20 fps |
| Main Stream 2 | 2560 * 1440 @ 30 fps |
| Main Stream 3 | 1920 * 1080 @ 30 fps – 1280 * 720 @ 30 fps |
| Sub-stream 1 | 1280 * 720 @ 30 fps |
| Sub-stream 2 | 720 * 480 @ 30 fps |
| Tri-stream | 352 * 288 @ 30 fps |
| IE Browser | IE8 – 11, Google Chrome (Lower Than Ver44), Firefox (Lower Than Ver53), Mac Safari (Lower Than Version 12) |
| Smart Phone | iPhone, iPad, Android, Android Pad |
| Intelligent Analysis | Intrusion Detection, Line Cross Detection, Loiter Detection, People Gather Detection |
| Recognition | Face Detection and Recognition (Max. Support 30,000 faces) |
| Day/Night | Color/ B&W (IR-CUT) |
| Image Configuration | Saturation/Brightness/Contrast /Sharpness, Mirror, 3DNR White Balance, FLK (Flicker Control), Video Tampering |
